CASE STUDY: SOUTHERN GREECE W.W.T.P.

Case StudySouthern Greece W.W.T.P.
LocationSouthern Greece
TargetSludge Elimination
Populations Equivalent200 000
Flowrate38 000-40 000 m3/day
Treated wastewaterMunicipal
Reduction100%
ParameterSuspended SolidsCODTNTP
Unitsmg/lmg/lmg/lmg/l
Input (average)100400707
Sludge Production Before Application (average)30-35 (tn/day)
Sludge Production After Application (average) 0 (tn /day)

REMARKS

  • The total reduction of excess sludge occurred with anaerobic digestion stage not in operation
  • The electricity reduced to approximately 15% after the application of our bacterial products
  • The SVI values in the sedimentation tanks were improved

CASE STUDY: NORTHERN GREECE W.W.T.P.

Case StudyNorthern Greece W.W.T.P.
LocationNorthern Greece
TargetSludge Elimination
Populations Equivalent120 000
Flowrate29 000 m3/day
Treated wastewaterMunicipal
Reduction100%
ParameterSuspended SolidsCODTNTP
Unitsmg/lmg/lmg/lmg/l
Input (average)2504005512
Sludges Production Before Application (average)
20-25 (tn/day)
Sludge Production After Application (average)0(tn/day)

REMARKS

  • Total reduction of excess sludge
  • The electricity consumption in the aerobic zone has reduced to approximately 25% after the application of the Ydro Process®
  • The SVI values in the sedimentation tanks were improved

CASE STUDY: NORTHERN GREECE SEWER SYSTEM

Case StudySewer System
LocationNorthern Greece
TargetOdour Control
Populations Equivalent12 000
Flowrate2500 m3/day
Treated wastewaterMunicipal
Reduction100%
ParameterSuspended SolidsCODTNTP
Unitsmg/lmg/lmg/lmg/l
Input (average)2504005512
Sludge Production Before Application (average)20-25 (tn/day)
Sludge Production After Application (average)0 (tn/day)

REMARKS

  • The wastewater parameters entering the WWTP were significantly reduced resulting in the overall reduction of incoming loading.
  • Odors, fats, oils and grease in the sewer grid, manholes and pumping stations were eliminated.
  • Sewer pipelines and pumping stations were cleaned and therefore the standard cleaning maintenance was not required

CASE STUDY: DAIRY INDUSTRY

Case StudyDAIRY INDUSTRY
LocationNorthern Greece
TargetSludge Elimination
Populations Equivalent80 000
Flowrate2500 m3/day
Treated wastewaterIndustrial – Dairy
Reduction100%
ParameterSuspended SolidsCODTNTP
Unitsmg/lmg/lmg/lmg/l
Input (average)80250011050
Sludge Production Before Application (average)2-3 (tn/day)
Sludge Production After Application (average)0 (tn/day)

REMARKS

  • Total reduction of excess sludge
  • The output parameters were improved
  • The odour problem was solved
  • The SVI values in the sedimentation tanks were improved

CASE STUDY: POULTRY SLAUGHTERHOUSE

Case StudyPOULTRY SLAUGHTERHOUSE
LocationNorthern Greece
TargetSludge and FOG Elimination
Populations Equivalent15 000
Flowrate300 m3/day
Treated wastewaterIndustrial – Slaughterhouse
Reduction100%
ParameterSuspended SolidsCODTNTP
Unitsmg/lmg/lmg/lmg/l
Input (average)150550080-9015-20
Sludge Production Before Application (average)12-18 (tn/day)
Sludge Production After Application (average)0 (tn/day)

REMARKS

  • Elimination of produced excess sludge and all used chemical additives
  • Total odor control of the plant
  • The FOG production was eliminated reducing transportation and disposal cost

CASE STUDY: LAKE REHABILITATION

Case StudyLAKE REHABILITATION
LocationNorthern Greece
TargetWater Quality Improvement & Odour Control
Populations Equivalent280 000 m3
Flowrate< 30 m3 /hr
Treated wastewaterSurface &Treated sewage water

REMARKS

  • Two lakes were treated
  • Lake No1 approximate volume 30 000 m3 and Lake No2 of 250 000 m3
  • The inflow id surface water and effluent from a wastewater treatment plant
  • The implementation target is rehabilitation of the two lakes
  • Combination of Facultative Microorganisms were used over three months
  • An increased dosage was used during the cultivation period (first month of application)
  • Total microbial product quantity used was approximately 110 kg
  • All monitored parameters (Turbidity, TN, TP etc.) were improved and the rehabilitation was achieved

CASE STUDY: VERIA W.W.T.P.

Case StudyVERIA W.W.T.P
Location
Northern Greece
Target
Sludge Elimination
Population Equivalent
60 000
Flowrate
11 000 – 13 000 m3/day
Treated wastewater
Municipal
Project Initiation
15/07/2012
Reduction100%
ParameterSuspended SolidsCODTNTP
Unitsmg/lmg/lmg/lmg/l
Input (average)4005007515
Sludge Production Before Application (average)15-20 (tn/day)
Sludge Production After Application (average) 0 (tn/day)

REMARKS

  • The plant also receives up to 100 tn/day of external sludge from other wastewater treatment plants, which is equivalent to a population of 500 000 people
  • The electricity consumption in the aerobic zone has been reduced to at least 50% after the application of our bacterial products “

CASE STUDY: GORKI-10 W.W.T.P.

Case Study
GORKI-10 W.W.T.P.
Location
Russia, Moscow region
Population Equivalent
10 000
Type of treatment plant
Classic
Design capacity
10 000 m3/day
Flowrate per day (average flowrate during 12 months)
3500 m3
Treated wastewater
Municipal
Reduction84.01%
ParameterCODNH4-NTN
Unitsmg/l
mg/l
mg/l
Input (average)5073031
Sludge Production Before Application (average)12.51 (tn/day)
Sludge Productin After Application (average)2 (tn/day)

REMARKS

  • The reduction of excess sludge
  • The odour problem was solved
  • The SVI values in the sedimentation tanks were improved

CASE STUDY: DRUSKININKAI W.W.T.P

Case StudyDruskininkai W.W.T.P.
LocationSouthern Lithuania
TargetSludge & Odour Elimination
Populations Equivalent15 000
Flowrate4 600 m3/day
Treated wastewaterMunicipal
Reduction100%
ParameterSuspended SolidsCODTNTP
Unitsmg/lmg/lmg/lmg/l
Input (average)n/a449
549
Sludge Production Before Application (average)
6 (tn/day)
Sludge Production After Application (average)
0 (tn/day)

REMARKS

  • Total reduction of excess sludge
  • Improved effluent parameters
  • The odour problem was solved
  • Cost reduction
